Silero VAD语音活动检测模型

Silero VAD 是由 Silero AI 团队开发的一个开源、轻量级且高性能的语音活动检测(VAD)模型。

它旨在检测音频流中的语音段,帮助系统知道何时有人在说话,何时是静音。

  • 高精度和低延迟:在 CPU 上处理约 30 毫秒的音频块可在 1 毫秒内完成,使用 ONNX 或 GPU 加速时甚至更快。
  • 体积小:JIT 模型大约为 1-2 MB。
  • 多语言且健壮:在覆盖数千种语言和嘈杂环境的巨大多样化数据集上进行训练。
  • 灵活的采样率:支持 8 kHz 和 16 kHz 音频。
“卓越的质量……高度便携。没有任何限制。支持 8 kHz 和 16 kHz。模型小于 1 MB……在 100 多种语言上进行了训练,泛化效果良好。单个块约需 1 毫秒。”

要在 Python 中使用,请安装依赖项。

pip install torch torchaudio onnxruntime soundfile

pip install silero-vad

Python 代码:

from silero_vad import load_silero_vad, read_audio, get_speech_timestamps

model = load_silero_vad()
wav = read_audio('nuri.mp3')
speech_timestamps = get_speech_timestamps(
  wav,
  model,
  return_seconds=True,  # 返回以秒为单位的语音时间戳(默认为样本)
)

print(speech_timestamps)
[{'start': 4.0, 'end': 4.4},
 {'start': 7.7, 'end': 10.1},
 {'start': 15.9, 'end': 16.7},
 {'start': 18.6, 'end': 21.0},
 {'start': 22.9, 'end': 28.2},
 {'start': 29.1, 'end': 31.9},
 {'start': 32.5, 'end': 33.5},
 {'start': 33.7, 'end': 35.9},
 {'start': 37.0, 'end': 38.4},
 {'start': 41.7, 'end': 44.4},
 {'start': 44.7, 'end': 45.1},
 {'start': 45.6, 'end': 46.3},
 {'start': 46.7, 'end': 47.3},
 {'start': 49.2, 'end': 51.3},
 {'start': 51.5, 'end': 57.9},
 {'start': 58.1, 'end': 58.7},
 {'start': 58.8, 'end': 59.2},
 {'start': 59.9, 'end': 60.7},
 {'start': 61.3, 'end': 61.7}]

使用 Torch:

import torch
torch.set_num_threads(1)

model, utils = torch.hub.load(repo_or_dir='snakers4/silero-vad', model='silero_vad')
(get_speech_timestamps, _, read_audio, _, _) = utils

wav = read_audio('nuri.mp3')
speech_timestamps = get_speech_timestamps(
  wav,
  model,
  return_seconds=True,  # 返回以秒为单位的语音时间戳(默认为样本)
)

print(speech_timestamps)
[{'start': 4.0, 'end': 4.4},
 {'start': 7.7, 'end': 10.1},
 {'start': 15.9, 'end': 16.7},
 {'start': 18.6, 'end': 21.0},
 {'start': 22.9, 'end': 28.2},
 {'start': 29.1, 'end': 31.9},
 {'start': 32.5, 'end': 33.5},
 {'start': 33.7, 'end': 35.9},
 {'start': 37.0, 'end': 38.4},
 {'start': 41.7, 'end': 44.4},
 {'start': 44.7, 'end': 45.1},
 {'start': 45.6, 'end': 46.3},
 {'start': 46.7, 'end': 47.3},
 {'start': 49.2, 'end': 51.3},
 {'start': 51.5, 'end': 57.9},
 {'start': 58.1, 'end': 58.7},
 {'start': 58.8, 'end': 59.2},
 {'start': 59.9, 'end': 60.7},
 {'start': 61.3, 'end': 61.7}]

还有其他语言的实现。让我们在 C++ 中运行。

docker pull gcc:12.2.0-bullseye
wget https://github.com/microsoft/onnxruntime/releases/download/v1.12.1/onnxruntime-linux-x64-1.12.1.tgz
tar -xzf onnxruntime-linux-x64-1.12.1.tgz

cd onnxruntime-linux-x64-1.12.1/

silero-vad-onnx.cpp

#ifndef _CRT_SECURE_NO_WARNINGS
#define _CRT_SECURE_NO_WARNINGS
#endif

#include <iostream>
#include <vector>
#include <sstream>
#include <cstring>
#include <limits>
#include <chrono>
#include <iomanip>
#include <memory>
#include <string>
#include <stdexcept>
#include <cstdio>
#include <cstdarg>
#include <cmath>    // for std::rint
#if __cplusplus < 201703L
#include <memory>
#endif

//#define __DEBUG_SPEECH_PROB___

#include "onnxruntime_cxx_api.h"
#include "wav.h" // For reading WAV files

// timestamp_t class: stores the start and end (in samples) of a speech segment.
class timestamp_t {
public:
    int start;
    int end;

    timestamp_t(int start = -1, int end = -1)
        : start(start), end(end) { }

    timestamp_t& operator=(const timestamp_t& a) {
        start = a.start;
        end = a.end;
        return *this;
    }

    bool operator==(const timestamp_t& a) const {
        return (start == a.start && end == a.end);
    }

    // Returns a formatted string of the timestamp.
    std::string c_str() const {
        return format("{start:%08d, end:%08d}", start, end);
    }
private:
    // Helper function for formatting.
    std::string format(const char* fmt, ...) const {
        char buf[256];
        va_list args;
        va_start(args, fmt);
        const auto r = std::vsnprintf(buf, sizeof(buf), fmt, args);
        va_end(args);
        if (r < 0)
            return {};
        const size_t len = r;
        if (len < sizeof(buf))
            return std::string(buf, len);
#if __cplusplus >= 201703L
        std::string s(len, '\0');
        va_start(args, fmt);
        std::vsnprintf(s.data(), len + 1, fmt, args);
        va_end(args);
        return s;
#else
        auto vbuf = std::unique_ptr<char[]>(new char[len + 1]);
        va_start(args, fmt);
        std::vsnprintf(vbuf.get(), len + 1, fmt, args);
        va_end(args);
        return std::string(vbuf.get(), len);
#endif
    }
};

// VadIterator class: uses ONNX Runtime to detect speech segments.
class VadIterator {
private:
    // ONNX Runtime resources
    Ort::Env env;
    Ort::SessionOptions session_options;
    std::shared_ptr<Ort::Session> session = nullptr;
    Ort::AllocatorWithDefaultOptions allocator;
    Ort::MemoryInfo memory_info = Ort::MemoryInfo::CreateCpu(OrtArenaAllocator, OrtMemTypeCPU);

    // ----- Context-related additions -----
    const int context_samples = 64;  // For 16kHz, 64 samples are added as context.
    std::vector<float> _context;     // Holds the last 64 samples from the previous chunk (initialized to zero).

    // Original window size (e.g., 32ms corresponds to 512 samples)
    int window_size_samples;
    // Effective window size = window_size_samples + context_samples
    int effective_window_size;

    // Additional declaration: samples per millisecond
    int sr_per_ms;

    // ONNX Runtime input/output buffers
    std::vector<Ort::Value> ort_inputs;
    std::vector<const char*> input_node_names = { "input", "state", "sr" };
    std::vector<float> input;
    unsigned int size_state = 2 * 1 * 128;
    std::vector<float> _state;
    std::vector<int64_t> sr;
    int64_t input_node_dims[2] = {};
    const int64_t state_node_dims[3] = { 2, 1, 128 };
    const int64_t sr_node_dims[1] = { 1 };
    std::vector<Ort::Value> ort_outputs;
    std::vector<const char*> output_node_names = { "output", "stateN" };

    // Model configuration parameters
    int sample_rate;
    float threshold;
    int min_silence_samples;
    int min_silence_samples_at_max_speech;
    int min_speech_samples;
    float max_speech_samples;
    int speech_pad_samples;
    int audio_length_samples;

    // State management
    bool triggered = false;
    unsigned int temp_end = 0;
    unsigned int current_sample = 0;
    int prev_end;
    int next_start = 0;
    std::vector<timestamp_t> speeches;
    timestamp_t current_speech;

    // Loads the ONNX model.
    void init_onnx_model(const std::string& model_path) {
        init_engine_threads(1, 1);
        session = std::make_shared<Ort::Session>(env, model_path.c_str(), session_options);
    }

    // Initializes threading settings.
    void init_engine_threads(int inter_threads, int intra_threads) {
        session_options.SetIntraOpNumThreads(intra_threads);
        session_options.SetInterOpNumThreads(inter_threads);
        session_options.SetGraphOptimizationLevel(GraphOptimizationLevel::ORT_ENABLE_ALL);
    }

    // Resets internal state (_state, _context, etc.)
    void reset_states() {
        std::memset(_state.data(), 0, _state.size() * sizeof(float));
        triggered = false;
        temp_end = 0;
        current_sample = 0;
        prev_end = next_start = 0;
        speeches.clear();
        current_speech = timestamp_t();
        std::fill(_context.begin(), _context.end(), 0.0f);
    }

    // Inference: runs inference on one chunk of input data.
    // data_chunk is expected to have window_size_samples samples.
    void predict(const std::vector<float>& data_chunk) {
        // Build new input: first context_samples from _context, followed by the current chunk (window_size_samples).
        std::vector<float> new_data(effective_window_size, 0.0f);
        std::copy(_context.begin(), _context.end(), new_data.begin());
        std::copy(data_chunk.begin(), data_chunk.end(), new_data.begin() + context_samples);
        input = new_data;

        // Create input tensor (input_node_dims[1] is already set to effective_window_size).
        Ort::Value input_ort = Ort::Value::CreateTensor<float>(
            memory_info, input.data(), input.size(), input_node_dims, 2);
        Ort::Value state_ort = Ort::Value::CreateTensor<float>(
            memory_info, _state.data(), _state.size(), state_node_dims, 3);
        Ort::Value sr_ort = Ort::Value::CreateTensor<int64_t>(
            memory_info, sr.data(), sr.size(), sr_node_dims, 1);
        ort_inputs.clear();
        ort_inputs.emplace_back(std::move(input_ort));
        ort_inputs.emplace_back(std::move(state_ort));
        ort_inputs.emplace_back(std::move(sr_ort));

        // Run inference.
        ort_outputs = session->Run(
            Ort::RunOptions{ nullptr },
            input_node_names.data(), ort_inputs.data(), ort_inputs.size(),
            output_node_names.data(), output_node_names.size());

        float speech_prob = ort_outputs[0].GetTensorMutableData<float>()[0];
        float* stateN = ort_outputs[1].GetTensorMutableData<float>();
        std::memcpy(_state.data(), stateN, size_state * sizeof(float));
        current_sample += static_cast<unsigned int>(window_size_samples); // Advance by the original window size.

        // If speech is detected (probability >= threshold)
        if (speech_prob >= threshold) {
#ifdef __DEBUG_SPEECH_PROB___
            float speech = current_sample - window_size_samples;
            printf("{ start: %.3f s (%.3f) %08d}\n", 1.0f * speech / sample_rate, speech_prob, current_sample - window_size_samples);
#endif
            if (temp_end != 0) {
                temp_end = 0;
                if (next_start < prev_end)
                    next_start = current_sample - window_size_samples;
            }
            if (!triggered) {
                triggered = true;
                current_speech.start = current_sample - window_size_samples;
            }
            // Update context: copy the last context_samples from new_data.
            std::copy(new_data.end() - context_samples, new_data.end(), _context.begin());
            return;
        }

        // If the speech segment becomes too long.
        if (triggered && ((current_sample - current_speech.start) > max_speech_samples)) {
            if (prev_end > 0) {
                current_speech.end = prev_end;
                speeches.push_back(current_speech);
                current_speech = timestamp_t();
                if (next_start < prev_end)
                    triggered = false;
                else
                    current_speech.start = next_start;
                prev_end = 0;
                next_start = 0;
                temp_end = 0;
            }
            else {
                current_speech.end = current_sample;
                speeches.push_back(current_speech);
                current_speech = timestamp_t();
                prev_end = 0;
                next_start = 0;
                temp_end = 0;
                triggered = false;
            }
            std::copy(new_data.end() - context_samples, new_data.end(), _context.begin());
            return;
        }

        if ((speech_prob >= (threshold - 0.15)) && (speech_prob < threshold)) {
            // When the speech probability temporarily drops but is still in speech, update context without changing state.
            std::copy(new_data.end() - context_samples, new_data.end(), _context.begin());
            return;
        }

        if (speech_prob < (threshold - 0.15)) {
#ifdef __DEBUG_SPEECH_PROB___
            float speech = current_sample - window_size_samples - speech_pad_samples;
            printf("{ end: %.3f s (%.3f) %08d}\n", 1.0f * speech / sample_rate, speech_prob, current_sample - window_size_samples);
#endif
            if (triggered) {
                if (temp_end == 0)
                    temp_end = current_sample;
                if (current_sample - temp_end > min_silence_samples_at_max_speech)
                    prev_end = temp_end;
                if ((current_sample - temp_end) >= min_silence_samples) {
                    current_speech.end = temp_end;
                    if (current_speech.end - current_speech.start > min_speech_samples) {
                        speeches.push_back(current_speech);
                        current_speech = timestamp_t();
                        prev_end = 0;
                        next_start = 0;
                        temp_end = 0;
                        triggered = false;
                    }
                }
            }
            std::copy(new_data.end() - context_samples, new_data.end(), _context.begin());
            return;
        }
    }

public:
    // Process the entire audio input.
    void process(const std::vector<float>& input_wav) {
        reset_states();
        audio_length_samples = static_cast<int>(input_wav.size());
        // Process audio in chunks of window_size_samples (e.g., 512 samples)
        for (size_t j = 0; j < static_cast<size_t>(audio_length_samples); j += static_cast<size_t>(window_size_samples)) {
            if (j + static_cast<size_t>(window_size_samples) > static_cast<size_t>(audio_length_samples))
                break;
            std::vector<float> chunk(&input_wav[j], &input_wav[j] + window_size_samples);
            predict(chunk);
        }
        if (current_speech.start >= 0) {
            current_speech.end = audio_length_samples;
            speeches.push_back(current_speech);
            current_speech = timestamp_t();
            prev_end = 0;
            next_start = 0;
            temp_end = 0;
            triggered = false;
        }
    }

    // Returns the detected speech timestamps.
    const std::vector<timestamp_t> get_speech_timestamps() const {
        return speeches;
    }

    // Public method to reset the internal state.
    void reset() {
        reset_states();
    }

public:
    // Constructor: sets model path, sample rate, window size (ms), and other parameters.
    // The parameters are set to match the Python version.
    VadIterator(const std::string ModelPath,
        int Sample_rate = 16000, int windows_frame_size = 32,
        float Threshold = 0.5, int min_silence_duration_ms = 100,
        int speech_pad_ms = 30, int min_speech_duration_ms = 250,
        float max_speech_duration_s = std::numeric_limits<float>::infinity())
        : sample_rate(Sample_rate), threshold(Threshold), speech_pad_samples(speech_pad_ms), prev_end(0)
    {
        sr_per_ms = sample_rate / 1000;  // e.g., 16000 / 1000 = 16
        window_size_samples = windows_frame_size * sr_per_ms; // e.g., 32ms * 16 = 512 samples
        effective_window_size = window_size_samples + context_samples; // e.g., 512 + 64 = 576 samples
        input_node_dims[0] = 1;
        input_node_dims[1] = effective_window_size;
        _state.resize(size_state);
        sr.resize(1);
        sr[0] = sample_rate;
        _context.assign(context_samples, 0.0f);
        min_speech_samples = sr_per_ms * min_speech_duration_ms;
        max_speech_samples = (sample_rate * max_speech_duration_s - window_size_samples - 2 * speech_pad_samples);
        min_silence_samples = sr_per_ms * min_silence_duration_ms;
        min_silence_samples_at_max_speech = sr_per_ms * 98;
        init_onnx_model(ModelPath);
    }
};

int main() {
    // Read the WAV file (expects 16000 Hz, mono, PCM).
    wav::WavReader wav_reader("audio/en.wav"); // File located in the "audio" folder.
    int numSamples = wav_reader.num_samples();
    std::vector<float> input_wav(static_cast<size_t>(numSamples));
    for (size_t i = 0; i < static_cast<size_t>(numSamples); i++) {
        input_wav[i] = static_cast<float>(*(wav_reader.data() + i));
    }

    // Set the ONNX model path (file located in the "model" folder).
    std::string model_path = "model/silero_vad.onnx";

    // Initialize the VadIterator.
    VadIterator vad(model_path);

    // Process the audio.
    vad.process(input_wav);

    // Retrieve the speech timestamps (in samples).
    std::vector<timestamp_t> stamps = vad.get_speech_timestamps();

    // Convert timestamps to seconds and round to one decimal place (for 16000 Hz).
    const float sample_rate_float = 16000.0f;
    for (size_t i = 0; i < stamps.size(); i++) {
        float start_sec = std::rint((stamps[i].start / sample_rate_float) * 10.0f) / 10.0f;
        float end_sec = std::rint((stamps[i].end / sample_rate_float) * 10.0f) / 10.0f;
        std::cout << "Speech detected from "
            << std::fixed << std::setprecision(1) << start_sec
            << " s to "
            << std::fixed << std::setprecision(1) << end_sec
            << " s" << std::endl;
    }

    // Optionally, reset the internal state.
    vad.reset();

    return 0;
}

lib/wav.h

// Copyright (c) 2016 Personal (Binbin Zhang)
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//   http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

#ifndef FRONTEND_WAV_H_
#define FRONTEND_WAV_H_

#include <assert.h>
#include <stdint.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>

#include <string>

#include <iostream>

// #include "utils/log.h"

namespace wav {

struct WavHeader {
  char riff[4];  // "riff"
  unsigned int size;
  char wav[4];  // "WAVE"
  char fmt[4];  // "fmt "
  unsigned int fmt_size;
  uint16_t format;
  uint16_t channels;
  unsigned int sample_rate;
  unsigned int bytes_per_second;
  uint16_t block_size;
  uint16_t bit;
  char data[4];  // "data"
  unsigned int data_size;
};

class WavReader {
 public:
  WavReader() : data_(nullptr) {}
  explicit WavReader(const std::string& filename) { Open(filename); }

  bool Open(const std::string& filename) {
    FILE* fp = fopen(filename.c_str(), "rb"); //文件读取
    if (NULL == fp) {
      std::cout << "Error in read " << filename;
      return false;
    }

    WavHeader header;
    fread(&header, 1, sizeof(header), fp);
    if (header.fmt_size < 16) {
      printf("WaveData: expect PCM format data "
              "to have fmt chunk of at least size 16.\n");
      return false;
    } else if (header.fmt_size > 16) {
      int offset = 44 - 8 + header.fmt_size - 16;
      fseek(fp, offset, SEEK_SET);
      fread(header.data, 8, sizeof(char), fp);
    }
    // check "riff" "WAVE" "fmt " "data"

    // Skip any sub-chunks between "fmt" and "data".  Usually there will
    // be a single "fact" sub chunk, but on Windows there can also be a
    // "list" sub chunk.
    while (0 != strncmp(header.data, "data", 4)) {
      // We will just ignore the data in these chunks.
      fseek(fp, header.data_size, SEEK_CUR);
      // read next sub chunk
      fread(header.data, 8, sizeof(char), fp);
    }

    if (header.data_size == 0) {
        int offset = ftell(fp);
        fseek(fp, 0, SEEK_END);
        header.data_size = ftell(fp) - offset;
        fseek(fp, offset, SEEK_SET);
    }

    num_channel_ = header.channels;
    sample_rate_ = header.sample_rate;
    bits_per_sample_ = header.bit;
    int num_data = header.data_size / (bits_per_sample_ / 8);
    data_ = new float[num_data]; // Create 1-dim array
    num_samples_ = num_data / num_channel_;

    std::cout << "num_channel_    :" << num_channel_ << std::endl;
    std::cout << "sample_rate_    :" << sample_rate_ << std::endl;
    std::cout << "bits_per_sample_:" << bits_per_sample_ << std::endl;
    std::cout << "num_samples     :" << num_data << std::endl;
    std::cout << "num_data_size   :" << header.data_size << std::endl;

    switch (bits_per_sample_) {
        case 8: {
            char sample;
            for (int i = 0; i < num_data; ++i) {
                fread(&sample, 1, sizeof(char), fp);
                data_[i] = static_cast<float>(sample) / 32768;
            }
            break;
        }
        case 16: {
            int16_t sample;
            for (int i = 0; i < num_data; ++i) {
                fread(&sample, 1, sizeof(int16_t), fp);
                data_[i] = static_cast<float>(sample) / 32768;
            }
            break;
        }
        case 32:
        {
            if (header.format == 1) //S32
            {
                int sample;
                for (int i = 0; i < num_data; ++i) {
                    fread(&sample, 1, sizeof(int), fp);
                    data_[i] = static_cast<float>(sample) / 32768;
                }
            }
            else if (header.format == 3) // IEEE-float
            {
                float sample;
                for (int i = 0; i < num_data; ++i) {
                    fread(&sample, 1, sizeof(float), fp);
                    data_[i] = static_cast<float>(sample);
                }
            }
            else {
                printf("unsupported quantization bits\n");
            }
            break;
        }
        default:
            printf("unsupported quantization bits\n");
            break;
    }

    fclose(fp);
    return true;
  }

  int num_channel() const { return num_channel_; }
  int sample_rate() const { return sample_rate_; }
  int bits_per_sample() const { return bits_per_sample_; }
  int num_samples() const { return num_samples_; }

  ~WavReader() {
    delete[] data_;
  }

  const float* data() const { return data_; }

 private:
  int num_channel_;
  int sample_rate_;
  int bits_per_sample_;
  int num_samples_;  // sample points per channel
  float* data_;
};

class WavWriter {
 public:
  WavWriter(const float* data, int num_samples, int num_channel,
            int sample_rate, int bits_per_sample)
      : data_(data),
        num_samples_(num_samples),
        num_channel_(num_channel),
        sample_rate_(sample_rate),
        bits_per_sample_(bits_per_sample) {}

  void Write(const std::string& filename) {
    FILE* fp = fopen(filename.c_str(), "w");
    // init char 'riff' 'WAVE' 'fmt ' 'data'
    WavHeader header;
    char wav_header[44] = {0x52, 0x49, 0x46, 0x46, 0x00, 0x00, 0x00, 0x00, 0x57,
                           0x41, 0x56, 0x45, 0x66, 0x6d, 0x74, 0x20, 0x10, 0x00,
                           0x00, 0x00, 0x01, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
                           0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
                           0x64, 0x61, 0x74, 0x61, 0x00, 0x00, 0x00, 0x00};
    memcpy(&header, wav_header, sizeof(header));
    header.channels = num_channel_;
    header.bit = bits_per_sample_;
    header.sample_rate = sample_rate_;
    header.data_size = num_samples_ * num_channel_ * (bits_per_sample_ / 8);
    header.size = sizeof(header) - 8 + header.data_size;
    header.bytes_per_second =
        sample_rate_ * num_channel_ * (bits_per_sample_ / 8);
    header.block_size = num_channel_ * (bits_per_sample_ / 8);

    fwrite(&header, 1, sizeof(header), fp);

    for (int i = 0; i < num_samples_; ++i) {
      for (int j = 0; j < num_channel_; ++j) {
        switch (bits_per_sample_) {
          case 8: {
            char sample = static_cast<char>(data_[i * num_channel_ + j]);
            fwrite(&sample, 1, sizeof(sample), fp);
            break;
          }
          case 16: {
            int16_t sample = static_cast<int16_t>(data_[i * num_channel_ + j]);
            fwrite(&sample, 1, sizeof(sample), fp);
            break;
          }
          case 32: {
            int sample = static_cast<int>(data_[i * num_channel_ + j]);
            fwrite(&sample, 1, sizeof(sample), fp);
            break;
          }
        }
      }
    }
    fclose(fp);
  }

 private:
  const float* data_;
  int num_samples_;  // total float points in data_
  int num_channel_;
  int sample_rate_;
  int bits_per_sample_;
};

}  // namespace wav

#endif  // FRONTEND_WAV_H_

音频文件位于 audio/en.wav 中。

将模型放在 model/ 文件夹中。

cd /home/yeniguno/coding/silerovad/onnxruntime-linux-x64-1.12.1/model && wget --no-check-certificate -O silero_vad.onnx https://github.com/snakers4/silero-vad/raw/master/src/silero_vad/data/silero_vad.onnx

让我们构建:

cd /home/yeniguno/coding/silerovad/onnxruntime-linux-x64-1.12.1 && g++ -std=c++17 -I./include silero-vad-onnx.cpp -L./lib -lonnxruntime -o silero-vad-onnx

Makefile

# Makefile for Silero VAD Project

CXX = g++
CXXFLAGS = -std=c++17 -Wall -O2
INCLUDES = -I./include
LIBS = -L./lib -lonnxruntime
RPATH = -Wl,-rpath,./lib
TARGET = silero-vad-onnx
SOURCE = silero-vad-onnx.cpp

# Build with embedded runtime path (recommended)
$(TARGET): $(SOURCE)
 $(CXX) $(CXXFLAGS) $(INCLUDES) $(SOURCE) $(LIBS) $(RPATH) -o $(TARGET)

# Build without embedded runtime path (requires LD_LIBRARY_PATH)
simple: $(SOURCE)
 $(CXX) $(CXXFLAGS) $(INCLUDES) $(SOURCE) $(LIBS) -o $(TARGET)

# Clean build artifacts
clean:
 rm -f $(TARGET)

# Run the program
run: $(TARGET)
 ./$(TARGET)

# Run with library path (use this if you built with 'make simple')
run-with-lib: $(TARGET)
 LD_LIBRARY_PATH=./lib:$$LD_LIBRARY_PATH ./$(TARGET)

# Debug build
debug: CXXFLAGS += -g -DDEBUG
debug: $(TARGET)

.PHONY: clean run run-with-lib debug simple

run_vad.sh

#!/bin/bash

# Silero VAD Runner Script
# This script ensures the program runs with the correct library path

# Change to the script's directory
cd "$(dirname "$0")"

# Check if the executable exists
if [ ! -f "./silero-vad-onnx" ]; then
    echo "Executable not found. Building the project..."
    make
    if [ $? -ne 0 ]; then
        echo "Build failed!"
        exit 1
    fi
fi

# Check if model exists
if [ ! -f "./model/silero_vad.onnx" ]; then
    echo "Model file not found. Downloading..."
    mkdir -p model
    wget --no-check-certificate -O model/silero_vad.onnx https://github.com/snakers4/silero-vad/raw/master/src/silero_vad/data/silero_vad.onnx
    if [ $? -ne 0 ]; then
        echo "Failed to download model!"
        exit 1
    fi
fi

# Run the program
echo "Running Silero VAD..."
LD_LIBRARY_PATH=./lib:$LD_LIBRARY_PATH ./silero-vad-onnx

让我们运行它:

cd /home/yeniguno/coding/silerovad/onnxruntime-linux-x64-1.12.1 && ./run_vad.sh
Speech detected from 0.0 s to 2.1 s
Speech detected from 2.7 s to 4.9 s
Speech detected from 5.0 s to 6.8 s
Speech detected from 9.3 s to 13.4 s
Speech detected from 13.6 s to 15.2 s
Speech detected from 15.4 s to 15.8 s
Speech detected from 16.3 s to 17.9 s
Speech detected from 18.4 s to 19.6 s
Speech detected from 20.4 s to 37.6 s
Speech detected from 38.0 s to 38.9 s
Speech detected from 39.9 s to 43.3 s
Speech detected from 43.6 s to 44.6 s
Speech detected from 45.1 s to 46.8 s
Speech detected from 48.9 s to 50.0 s
Speech detected from 51.1 s to 53.4 s
Speech detected from 53.6 s to 60.0 s

原文链接:Silero VAD: The Lightweight, High‑Precision Voice Activity Detector

汇智网翻译整理,转载请标明出处
